The TS-7250-V3 is an extremely low-power, high-performance Single Board Computer powered by NXP i.MX 6UltraLite with the ARM® Cortex®-A7 core operating up to 696 MHz. Typical power usage is about 1 W, packed with up to 1 GB RAM, 4 GB eMMC flash, microSD, WiFi, and Bluetooth module with external u.FL antenna, and many industry-standard interfaces. It targets applications with strict power requirements, yet needs a high-performance system with wireless connectivity, like industrial automation, medical, automotive, industrial automation, smart energy, and many more.
ROBUST AND RUGGED ENGINEERING
Each component on the TS-7250-V3 has been carefully chosen to ensure not only reliable operation in the field but also to get maximum product lifespan for 10+ years. The fanless design of the TS-7250-V3 paired with the low-cost enclosure is able to withstand high vibration, high debris, and a wide temperature range of -40 °C to 85 °C.
RELIABLE DATA STORAGE
The onboard MLC eMMC flash is configurable as pseudo SLC (pSLC) memory for further reliability. Additionally, the TS-7250-V3 integrates Ferroelectric RAM (FRAM or FeRAM ) which combines non-volatile data storage with incredibly high read/write endurance for the ultimate in reliability for heavy data logging applications.
SHORT TIME TO MARKET WITH LONG TERM DEPLOYMENT
A productive out-of-the-box experience includes pre-installed Linux OS, development tools, and utilities for controlling all onboard interfaces such as DIO, UARTS, CAN bus, and more. The development kit makes sure you have all the necessary connections and cables to get off the ground quickly. The guaranteed 10+ year lifecycle ensures a long-term deployment in the field, free from expensive replacements that come from short, disposable lifecycles which are all too common.
HARDWARE DETAILS
The TS-7250-V3 Single Board Computer features:
- Processor – NXP i.MX 6UL (ARM Cortex-A7 @ 696MHz)
- Memory – 4GB MLC eMMC which can be configured to a more robust 2GB SLC eMMC
- RAM – Up to 1GB
- Storage – MicroSD slot supporting SDSC, SDHC, and SDXC MicroSD cards
- Wireless – 802.11 b/g/n; Bluetooth BLE
- On-board USB console output with Micro-USB connector
- Networking – 2x 10/100 Ethernet ports
- mikroBUS Socket
- 1x PWM
- 1x ADC
- 1x SPI
- 1x TTL UART
- XBee Socket
- Supports NimbeLink / Digi Cell Modem (Cellular or Wireless Mesh)
- Other I/O available:
- 2x USB Host Ports
- SPI Bus
- I2C Bus
- 2x CAN
- 2x RS-485
- RS-422
- 3x RS-232
- Expansion:
- PC-104 Port (Standard and Stack-Thru; Supporting ISA bus or GPIO)
- 5x Analog to Digital (ADC) Ports (30 VDC Analog In or x3 4-20mA)
- Other features – Watchdog timer
- Crypto Key Storage
- Accelerometer, Gyroscope, and Magnetometer
- Text LCD Header supporting 2x24 alphanumeric display
- DIO Header supporting matrix keypad
- 5V input Power
- Typical Power Consumption 1.0 W
- Fanless Temperature Range -40 °C to 85 °C
Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.
Arm and Cortex are registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
| CPU |
| Architecture |
Arm (Cortex A7) |
| Part Number |
i.MX 6UltraLite |
| CPU Speed |
696 MHz |
| CPU Cores (Max) |
1x |
| Core Specs |
| Base Memory Capacity |
512 MB |
| Maximum Memory Capacity |
1 GB |
| Storage |
| Base Flash Capacity |
4 GB |
| Maximum Flash Capacity |
16 GB |
| microSD Card Socket |
1x |
| FRAM |
2 KB |
| Other |
| Battery-Backed Real Time Clock |
1x |
| Crypto Key Storage |
Yes |
| General I/O |
| General-Purpose Input/Output (GPIO) Pins |
109x |
| Analog to Digital Ports (ADC) |
5x (30 VDC Analog In or x3 4-20mA) |
| Serial Interfaces |
| RS-232 Ports |
3x |
| RS-485 Ports |
2x |
| Peripheral Interfaces |
| USB Host Ports |
2x |
| PC/104 Ports |
1x (Standard and Stack-Thru; Extra GPIO on 40 Pin Connector) |
| Industrial Protocols |
| CAN Ports |
2x |
| Networking |
| 10/100 Ethernet Ports |
2x |
| Physical |
| Operating Supply Voltage |
5 VDC or 8 to 48 VDC |
| Fanless Temperature Range |
-40 °C to 85 °C |
| Radio Comms |
| WiFi Radio / Wireless LAN |
Yes (802.11b/g/n + Bluetooth 4.0+EDR w/ u.FL) |
| mikroBUS Socket |
1x |
| NimbeLink / Digi Cell Modem |
1x (Cellular or Wireless Mesh) |
| Software |
| Linux Kernel Version |
5.10 |
| Sensors |
| Accelerometer/Gyro |
Yes |
| Graphics / HMI |
| Text LCD Header |
1x |
TS-7250-V3 Block Diagram
(Download PDF version)
| Product Configuration |
| Part |
Description |
Price |
| TS-7250-V3-SMN1I |
TS-7250-V3 SBC with the i.MX6UL 696MHz Arm Cortex A7 512MB DDR3 RAM and 4GB eMMC Flash, 1 Ethernet (-40 to 85C)
|
Pricing
|
| TS-7250-V3-SMN2I |
TS-7250-V3 SBC with the i.MX6UL 696MHz ARM Cortex A7 512MB DDR3 RAM and 4GB eMMC Flash, 2 Ethernet, 2 CAN, Cellular Socket, MikroBus Socket (-40 to 85C)
|
Pricing
|
| TS-7250-V3-SMN2I-ST |
TS-7250-V3 SBC with the i.MX6UL 696MHz ARM Cortex A7 512MB DDR3 RAM and 4GB eMMC Flash, 2 Ethernet, 2 CAN, Cellular Socket, MikroBus Socket, Stack Thru (-40 to 85C)
|
Pricing
|
| TS-7250-V3-SMW8I |
TS-7250-V3 SBC with the i.MX6UL 696MHz Arm Cortex A7 512MB DDR3 RAM and 4GB eMMC Flash, 2 Ethernet, 2 CAN, Cellular Socket, MikroBus Socket, WiFi & Bluetooth w/ u.FL Antenna Connector, Crypto Key Storage, FRAM, Accelerometer/Magnetometer (-40 to 85C)
|
Pricing
|
| TS-7250-V3-SXW9I |
TS-7250-V3 SBC with the i.MX6UL 696MHz Arm Cortex A7 1GB DDR3 RAM and 16GB eMMC Flash, 2 Ethernet, 2 CAN, Cellular Socket, MikroBus Socket, WiFi & Bluetooth w/ u.FL Antenna Connector, Crypto Key Storage, FRAM, Accelerometer/Magnetometer (-40 to 85C)
|
Pricing
|
| Conformal Coated Product Configurations |
| Part |
Description |
Price |
| TS-7250-V3-SMN2I-CC |
Conformal Coated TS-7250-V3-SMN2I. TS-7250-V3 SBC with the i.MX6UL 696MHz ARM Cortex A7 512MB DDR3 RAM and 4GB eMMC Flash, 2 Ethernet, 2 CAN, Cellular Socket, MikroBus Socket (-40 to 85C)
|
Pricing
|
| TS-7250-V3-SMN2I-ST-CC |
Conformal Coated TS-7250-V3-SMN2I-ST. TS-7250-V3 SBC with the i.MX6UL 696MHz ARM Cortex A7 512MB DDR3 RAM and 4GB eMMC Flash, 2 Ethernet, 2 CAN, Cellular Socket, MikroBus Socket, Stack Thru (-40 to 85C)
|
Pricing
|
| TS-7250-V3-SMW8I-CC |
Conformal Coated TS-7250-V3-SMW8I. TS-7250-V3 SBC with the i.MX6UL 696MHz Arm Cortex A7 512MB DDR3 RAM and 4GB eMMC Flash, 2 Ethernet, 2 CAN, Cellular Socket, MikroBus Socket, WiFi & Bluetooth w/ u.FL Antenna Connector, Crypto Key Storage, FRAM, Accelerometer/Magnetometer (-40 to 85C)
|
Pricing
|
| Board Specific Peripherals |
| Part |
Description |
Price |
| TS-9422 |
TS-9422 POST code display board
|
$101
|
| Flash Media |
| Part |
Description |
Price |
| MSD-8GB-USB-7250-V3 |
TS-7250-V3 bootable 8GB Class 10 microSD card including ARM tool chain, Debian 12 Linux filesystem, documentation, and further binaries/utilities, includes USB reader
|
$63
|
| MSD-8GB-BLANK |
8GB Class 10 microSD card
|
$30
|
| MSD-8GB-7250-V3 |
TS-7250-V3 bootable 8GB Class 10 microSD card including ARM tool chain, Debian 12 Linux filesystem, documentation, and further binaries/utilities
|
$30
|
| Accessories and Extras |
| Part |
Description |
Price |
| TS-ADC16 |
PC/104 Peripheral with 16 channels of 16-bit ADC, 4 12-bit DAC, Digital I/O and 64-pin PC/104 connector
|
$218
|
| TS-BAT10 |
Intelligent Battery Back-up Board
|
$153
|
| TS-DIO24 |
PC/104 peripheral board with 24 digital I/O points
|
$55
|
| TS-DIO64 |
PC/104 peripheral board with 64 digital I/O points
|
$94
|
| TS-ISO485 |
Dual UART with RS-485 peripheral
|
$127
|
| TS-MULTI-104-GPRS |
PC/104 carrier board including the MTSMC-G2 quad-band GPRS module
|
$197
|
| TS-RELAY8 |
Software Controlled Relay Board
|
$120
|
| TS-SER1 |
PC/104 peripheral board provides one serial COM port
|
$39
|
| TS-SER2 |
2 port serial peripheral board with 8-bit PC/104 stack-thru bus connector
|
$101
|
| TS-SER4-FD-104 |
4 port serial card with 8-bit PC/104 stack-thru bus connector with full-duplex RS-485 and 16-bit PC/104 stack-thru bus (allows usage of IRQ10 to IRQ15)
|
$137
|
| TS-9700 |
Analog Board with 8-bit PC/104 stack-thru bus connector
|
$81
|
| CB7-05 |
Null modem cable with a DB9F at each end
|
$10
|
| CB-JUMPER-10-F-F-6 |
Quantity 10 female-to-female 6-inch red jumper wires for use with 0.1" headers
|
$7
|
| CB-JUMPER-10-M-M-6 |
Quantity 10 male-to-male 6-inch blue jumper wires for use with 0.1" headers
|
$7
|
| CB-USB-A-MICRO-GOLD |
3' USB 2.0 Type-A to Micro-B cable
|
$9
|
| TS-12W |
5VDC switching power supply peripheral
|
$39
|
| TS-13W |
8-30VDC input to 5VDC output low-profile power regulator
|
$43
|
| Power Supplies |
| Part |
Description |
Price |
| PS-5VDC-REG-2P1 |
Regulated 5 VDC, 2.5 A wall mounted power supply with 2 pin black screw terminal connector (100-240 VAC, 50-60 Hz, A-type Plug)
|
$26
|
| PS-12VDC-REG-2PBF3 |
Regulated 12 VDC, 2.5 A wall mounted power supply with 2 pin 3.81mm black flanged plug connector (100-240 VAC, 50-60 Hz, A-type Plug)
|
$21
|
| DIN Enclosures |
| Part |
Description |
Price |
| TS-ENC-104-72V3-1ETH-DIN |
126x134x51 High Grade Polymer Enclosure with DIN Clip for TS-7250-V3-SMN1I
|
$82
|
| TS-ENC-104-72V3-2ETH-DIN |
126x134x51 High Grade Polymer Enclosure with DIN Clip for TS-7250-V3-SMN2I, TS-7250-V3-SMW8I, TS-7250-V3-SXW9I
|
$82
|
| Enclosures |
| Part |
Description |
Price |
| TS-ENC-104-72V3-2ETH |
126x134x51 High Grade Polymer Enclosure for TS-7250-V3-SMN2I, TS-7250-V3-SMW8I, TS-7250-V3-SXW9I
|
$76
|
| TS-ENC-104-72V3-1ETH |
126x134x51 High Grade Polymer Enclosure for TS-7250-V3-SMN1I
|
$76
|
| Development Kits |
| Part |
Description |
Price |
| KIT-7250-V3-ENC |
Development kit includes: PS-12VDC-REG-2PBF3 power supply; CB-USB-A-MICRO-GOLD $9, RC-DB9 and CB7-05 cables; MSD-8GB-BLANK micro SD card and USB reader interface; jumpers, jumper wires and other hardware
|
$128
|
| KIT-7250-V3 |
Development kit includes: PS-PS-5VDC-REG-2P1 power supply; CB-USB-A-MICRO-GOLD, RC-DB9 and CB7-05 cables; MSD-8GB-BLANK micro SD card and USB reader interface; jumpers, jumper wires and other hardware
Includes packaged parts:
- PS-5VDC-REG-2P1: Regulated 5 VDC, 2.5 A wall mounted power supply with 2 pin black screw terminal connector (100-240 VAC, 50-60 Hz, A-type Plug)
- CB-USB-A-MICRO-GOLD: 3' USB 2.0 Type-A to Micro-B cable
- CB7-05: Null modem cable with a DB9F at each end
- MSD-8GB-BLANK: 8GB Class 10 microSD card
- RC-DB9: 10-pin header COM port adapter cable to DB-9
|
$133
|
