TS-9370

Low Power, High Performance 64-bit Single Board Computer

Lifecycle: Concept Design | Released: TBA | Guaranteed Availability: N/A

64-bit Industrial Single Board Computer

  • NXP i.MX9352 Dual Core 1.7GHz
  • 64-bit Arm® v8.2-A architecture
  • 2 GByte LPDDR4 RAM
  • mikroBUS Socket
  • Pricing $329 for Qty 100, $399 for Qty 1
Call us
No minimum order quantity on standard products.

our first 64-bit single board computer.

  • NXP i.MX9352 64-bit ARM® architecture
  • Two Cortex®-A55 processors operating up to 1.7 GHz
  • 2 GB LPDDR RAM
  • 32 GB eMMC (upgradable to 128GB)
  • Neural Processing Unit (NPU) 256 MACs operating at up to 1.0 GHz and 2 OPTS/MAC
  • Intel® MAX®10 FPGA

NXP i.MX9352 is an application processor that supports edge computing and machine learning acceleration with security and power efficiency. The SoC architecture has an Arm Cortex A55 dual core, a low-power security MCU, and a high-efficiency NPU. The SoC architecture is built with a dual Arm Cortex A55 core, low-power security MCU, and high-efficiency NPU to boost the computing capability with AI functions of the chip. The processors target consumer IoT products, industrial and automotive applications. Part of the EdgeVerse™ portfolio of intelligent edge solutions, the i.MX 93 family will be offered in commercial, industrial, extended industrial and automotive level qualification and backed by NXP’s product longevity program.

Rugged and Reliable.

Each component on the TS-9370 has been carefully chosen to ensure reliable operation in the field. Data is reliably stored in the onboard eMMC flash. The TS-9370's fanless design allows it to run cool without a heat sink. The TS-9370 can withstand high vibration, and even with two CPU cores running up to 1.7 GHz and tasked to their max, the system can operate at a wide temperature range of -40 °C to 85 °C. The TS-SILO power reserve solution allows 60 seconds for graceful shutdown to avoid filesystem corruption.

Custom Quickly.

The TS-9370 comes standard with the MikroBUS socket, allowing customers to add functionality via Click Boards. The vast library of MikroE Click Boards makes it extremely fast and easy for our customers to deploy complete applications, prototype new features, and roll out their custom Click Board designs quickly to add new features and support to existing applications cost-effectively.

Digital Ins and Outs

The rugged screw terminals provide a secure interface for communication and control of sensors, actuators, and other external equipment. The TS-9370 supports several DIO features found in industrial applications, such as 4-20 mA or 0-10 VDC analog inputs, and outputs capable of sinking 500 mA. Furthermore, digital outputs have fast electronic circuit breakers for equipment protection.

  • 2x CAN Port
  • DIO
  • 1x RS-232 Port
  • 1x RS-422 Port
  • 3x ADC (0-12 VDC or 4-20 mA)
  • 1x Nine-Axis (Gyro + Accelerometer + Compass) MEMS MotionTracking Device
  • 1x GPS
  • 1x I2C

embeddedTS provides complete documentation for our mature products, including manuals, schematics, mechanical drawings, etc. The most recent documentation files are always made available through our website. If you don't find the documentation you are looking for, contact support for more information. Also, please make sure to visit our Embedded Systems Support webpage, and our official documentation.

Documentation
Block Diagram
From the Blog:
Product Notices:
Subscribe to the Product Communication System (TS-PCS) for TS-9370 Notices
CPU
Architecture ARM
Part Number i.MX9352
Vendor NXP
CPU Speed 1.7 GHz
CPU Cores 2
Other
Battery-Backed Real Time Clock 1x
Serial Interfaces
RS-232 Ports 1x
RS-485 Ports 2x (or 1x RS-422)
I2C Ports 1x (Internal Header)
Peripheral Interfaces
USB Host Ports 4x (2.0)
Industrial Protocols
CAN Ports 2x (CAN-FD)
Physical
Fanless Temperature Range -40 °C to 85 °C
Radio Comms
Bluetooth Yes (5.0)
WiFi Radio / Wireless LAN Yes (802.11 a/b/g/n/ac)
mikroBUS Socket 1x
NimbeLink / Digi Cell Modem 1x
Sensors
Accelerometer/Gyro Yes
Magnetometer Yes
General I/O
Audio Codec, Speaker, Amp
Core Specs
DisplayPort 1.1a
Storage
RAM 1 GB (LPDDR4 Optional to 2GB)
Flash 8 GB (Optional to 128GB)
TS-9370 Block Diagram
TS-9370 Block Diagram Image

(Download PDF version)
