TS-TPC-8390 Front View TS-TPC-8390 Front View
TS-TPC-8390-4900 Interior View TS-TPC-8390-4900 Interior View
TS-TPC-8390-4900 Angled View TS-TPC-8390-4900 Angled View
TS-TPC-8390 Front View
TS-TPC-8390-4900 Interior View
TS-TPC-8390-4900 Angled View

TS-TPC-8390-4900

Combination Product

7" High End imx6 Mountable Panel PC with BSPs

Lifecycle: Fully Developed | Released: April 2015

Ideal for digital signage, HMI, and SCADA applications with an outstanding 10+ year lifecycle guarantee.

  • Connected 7" Touch Panel PC with WiFi, Bluetooth, and Gigabit Ethernet
  • Robust Connectivity with USB, SATA II, PCIe, RS-485, CAN, DIO, and More
  • Accelerated 3D Graphics with i.MX6 Optimized Yocto Linux v3.10
  • Flexible Data Storage: High Reliability SLC or High Capacity MLC eMMC Flash
  • Rugged, Industrial Environment Ready with Fanless -20°C to +70°C Range
$528 (Qty. 100) $591 (Qty. 1)
No minimum order quantity on standard products.
Contact Sales Get Support Order Now
Getting Started Manual
Carrier Board
TS-TPC-8390 Thumbnail

TS-TPC-8390

Computer-on-Module
TS-4900 Thumbnail

TS-4900

Our flagship touch panel PC solution suited for digital signage, HMI, and SCADA applications with an outstanding 10+ year lifecycle guarantee. Powered by the TS-4900 System-on-Module with it's solo or quad core NXP i.MX6 using the Arm® Cortex®-A9 core, the TS-TPC-8390-4900 is capable of hardware accelerated 3D graphics for attention-grabbing signage. It's just as much at home in a control and data acquisition environment with industry standard connectors and interfaces such as RS-232, RS-485, CAN, SPI, I2C, and GPIO brought out on the TS-8390 baseboard via TS-SOCKET connector. A 7" TFT WVGA resistive touch panel display with high brightness (800 nit) completes the solution. The TS-TPC-8390-4900 also has flexible data storage methods on the eMMC flash, providing SLC for high reliability or MLC for high capacity. A microSD card can also be used to boot from and/or store additional data, like a video playlist or data logging.

embeddedTS has partnered with a third-party vendor to provide anti-microbial, shock-absorbing, and super scratch-resistant film overlays. These films also protect screens from scratches, dirt, and abrasion. If interested, inquire with sales for more information and learn how to obtain a sample.

The TS-TPC-8390-4900 runs Linux, Windows Embedded Compact, Android, or QNX. Yocto with Linux Kernel v3.10 is installed by default and is configured to take full advantage of the hardware accelerated graphics and all other features of the TS-4900, like WiFi, Bluetooth, and Gigabit Ethernet. GUI development is made easy using Qt, GTK, DirectFB, and more. Familiar GNU development tools, like gcc and gdb, are also installed, making on-board development easy. Cross compile toolchains are also made available so you can develop using your favorite desktop IDE. Finally, as with most Linux distributions, other services like Apache Web Server, CGI-BIN, FTP, SSH, Telnet, Samba network services, etc. are available. An example CGI-BIN application has also been preloaded. Also included are utilities and applications to control DIO, SPI, and more so that you can get your product to market in record time.

New since May 2018: Debian 9 Stretch is now supported on all of our i.MX6 products, including the TS-4900. Images, drivers, and toolchains are available for download. For more information, visit the "Debian Stretch" section of the manual.

The TS-4900 is shipped with Yocto by default. The Yocto environment is a powerful, stable, and familiar software stack, including common Linux tools and interpreters. With Yocto, we provide an x86/x86_64 cross toolchain which supports common onboard libraries and integrates with QT Creator, and other IDEs. Yocto is also available to take full advantage of the i.MX6 GPU providing simple integration with QT Creator and IDEs for rapid development.

Windows Embedded Compact 2013 provides the flexibility and real-time support to help device manufacturers reduce time to market while creating easy-to-use, multi-touch intelligent systems that help enterprises improve worker productivity. You can purchase the TS-4900 with Windows Compact Embedded 2013 preloaded on the order tab (TS-4900-S-WIN-I or TS-4900-Q-WIN-I). You can download and install Debian from our website by referring to the Windows EC section of the manual.

Debian provides a massive repository of prebuilt applications and services as well as a long history of focusing on stability and support for the embedded market. You can download and install Debian from our website by referring to the Debian section of the manual.

The world's most popular mobile OS, now available on a robust embedded system. Android™ provides power development tools and a large community of developers. The distribution provided for the TS-4900 includes driver support for all of the available hardware interfaces, including many not available in the standard Android distributions. You can download and install Android from the TS-4900 Files Repository.

The QNX® Neutrino® RTOS is a full-featured and robust OS that scales down to meet the constrained resource requirements of realtime embedded systems. It is a true microkernel design and its modular architecture enable customers to create highly optimized and reliable systems with low total cost of ownership. You can download and install QNX from our website by referring to the QNX section of the manual.

As with all of our products, the source code, schematics, mechanical drawings, and manuals for the TS-TPC-8390-4900 are freely available for download in the resources tab. For the added peace of mind and confidence in our solution, a 45 day evaluation period, 1 year warranty, engineer-backed technical support, and 10+ year product availability are included with your purchase.

For more detailed information, please visit the System-on-Module and baseboard links shown below.

Linux® is the registered trademark of Linus Torvalds in the U.S. and other countries.
Arm and Cortex are registered trademarks of Arm Limited (or its subsidiaries) in the US and/or elsewhere.

embeddedTS provides complete documentation for our mature products, including manuals, schematics, mechanical drawings, etc. The most recent documentation files are always made available through our website. If you don't find the documentation you are looking for, contact support for more information. Also, please make sure to visit our Embedded Systems Support webpage, and our official documentation.

Documentation
Certification
Software Download
Video
News Article
Block Diagram
Third Party Documentation
Featured On
From the Blog:
Product Notices:
Subscribe to the Product Communication System (TS-PCS) for TS-TPC-8390-4900 Notices
CPU
Architecture Arm
Part Number i.MX6
Vendor NXP
CPU Speed 1.1 GHz (Solo or Quad Core)
Floating Point Unit Yes
CPU Cores (Max) 4x
Core Specs
Base Memory Capacity 1 GB
Maximum Memory Capacity 2 GB (2 GB Standard on Quad)
Memory Type DDR3
FPGA 4 k LUT
Watchdog Timer 2x
Storage
Base Flash Capacity 4 GB (2 GB pSLC or 4 GB MLC)
Flash Type eMMC
microSD Card Socket 1x
SATA Ports 1x
Other
Battery-Backed Real Time Clock 1x
Graphics Processing Unit Yes
Sensors
Temperature Sensor 2x
General I/O
General-Purpose Input/Output (GPIO) Pins 70x
PWM Ports 3x
Serial Interfaces
RS-232 Ports 4x
RS-485 Ports 2x (2x Half Duplex; Transceiver Required)
TTL-Level UART Ports 2x
SPI Ports 2x
I2C Ports 2x
I2S Audio Ports 1x
Peripheral Interfaces
USB Host Ports 1x
USB Device Ports 1x
USB OTG Ports 1x
PCI Express Bus 1x
Industrial Protocols
CAN Ports 2x
Networking
Gigabit Ethernet Ports 1x
Physical
Operating Supply Voltage 5 VDC
Minimum Power Consumption 0.50 W (Quad: 0.9 W)
Typical Power Consumption 1.30 W (Quad: 2.0 W)
Maximum Power Consumption 3.40 W (Quad: 10.4 W)
Fanless Temperature Range -20 °C to 70 °C
Width 200.0 mm
Length 42.0 mm
Height 140.0 mm
Software
Preloaded Software Yocto
Linux Kernel Version 3.10
Debian Linux Stretch (9.0)
Windows OS Embedded Compact 2013
Android OS 4.4.3 KitKat
Yocto Linux 2.2 Morty
Graphics / HMI
Screen Diagonal Size 7"
Touchscreen Yes
Screen Resolution 800x480
Speaker Yes
Touchscreen Type Resistive
Quantities
Product Configurations 1 10 25 50 100
TS-TPC-8390-2CAN $407 -- -- -- $391
TS-TPC-8390-SILVER $388 -- -- -- $371
TS-TPC-8390-2CAN-SILVER $407 -- -- -- $391
TS-4900-1024-S10S-C $203 $176 $171 $164 $157
TS-4900-1024-4096F-S8S-RTC-I $233 $208 $200 $190 $184
TS-4900-1024-4096F-S8S-RTC-WIFI-I $279 $254 $243 $232 $221
TS-4900-2048-4096F-Q10S-RTC-E $308 $283 $272 $260 $248
TS-4900-2048-4096F-Q10S-RTC-WIFI-E $354 $327 $315 $301 $287
TS-4900-S-CORE-I $279 $254 $243 $232 $221
TS-4900-Q-CORE-E $354 $327 $315 $301 $287
HS-21x21x15 Thumbnail
HS-21x21x15
In Accessories and Extras

CPU heatsink measuring 21x21x15mm recommended for i.MX6 quad core

Product Configuration
Part Description Price
TS-TPC-8390-2CAN Open mountable frame 7" touch panel computer with second CAN transceiver (system-on-module not included) Pricing
TS-TPC-8390-SILVER Open mountable frame 7" touch panel computer with silver bezel (system-on-module not included) Pricing
TS-TPC-8390-2CAN-SILVER Open mountable frame 7" touch panel computer with silver bezel and second CAN transceiver (system-on-module not included) Pricing
TS-4900-1024-S10S-C TS-4900 commercial grade (0 °C to 70 °C) System-on-Module with Solo 1GHz i.MX6 CPU and 1GB RAM (SD card required to boot sold separately) Pricing
TS-4900-1024-4096F-S8S-RTC-I TS-4900 industrial grade (-40 °C to 85 °C) System-on-Module with Solo 800MHz i.MX6 CPU, 1GB RAM, 4GB eMMC Flash with Linux and RTC Pricing
TS-4900-1024-4096F-S8S-RTC-WIFI-I TS-4900 industrial grade (-40 °C to 85 °C) System-on-Module with Solo 800MHz i.MX6 CPU, 1GB RAM, 4GB eMMC Flash with Linux, RTC and on-board WiFi & Bluetooth module Pricing
TS-4900-2048-4096F-Q10S-RTC-E TS-4900 extended temp. grade (-20 °C to 70 °C) System-on-Module with Quad 1GHz i.MX6 CPU, 2GB RAM, 4GB eMMC Flash with Linux and RTC Pricing
TS-4900-2048-4096F-Q10S-RTC-WIFI-E TS-4900 extended temp. grade (-20 °C to 70 °C) System-on-Module with Quad 1GHz i.MX6 CPU, 2GB RAM, 4GB eMMC Flash with Linux, RTC and on-board WiFi & Bluetooth module Pricing
Software Specific Product Configuration
Part Description Price
TS-4900-S-CORE-I TS-4900-1024-4096F-S8S-RTC-WIFI-I with Ubuntu Core, SoM with solo 800MHz i.MX6 CPU, 1GB RAM, 4GB eMMC flash, RTC and on-board WiFi/BT module (-40C to 85C) Pricing
TS-4900-Q-CORE-E TS-4900-2048-4096F-Q10S-RTC-WIFI-E with Ubuntu Core, SoM with quad 1GHz i.MX6 CPU, 2GB RAM, 4GB eMMC flash, RTC and on-board WiFi/BT module (-20C to 70C) Pricing
Flash Media
Part Description Price
MSD-8GB-CLASS10-4900 TS-4900 bootable 8GB Class 10 microSD card with Yocto Linux filesystem and further binaries/utilities $30
MSD-8GB-CLASS10-USB-4900 TS-4900 bootable 8GB Class 10 microSD card pre-loaded with Debian, includes USB reader $63
MSD-8GB-BLANK 8GB Class 10 microSD card $30
Accessories and Extras
Part Description Price
CB-JUMPER-10-F-F-6 Quantity 10 female-to-female 6-inch red jumper wires for use with 0.1" headers $7
HS-21x21x15 CPU heatsink measuring 21x21x15mm recommended for i.MX6 quad core $19
CN-TSSOCKET-M-10 Qty Ten (10) Male 100-Pin High Density Connectors for Custom Baseboard Design $50
CN-TSSOCKET-M-100 Qty One Hundred (100) Male 100-Pin High Density Connectors for Custom Baseboard Design $322
RC-DB9 10-pin header COM port adapter cable to DB-9 $5
CB-USB-AF5P 5-Pin Header to USB Connector $9
CB7-05 Null modem cable with a DB9F at each end $10
CB-DB9-Y DB-9 Y Cable $10
CB-ANT-SDMAC Antenna and cable for silex wifi module $15
Power Supplies
Part Description Price
PS-12VDC-REG-2P3 Regulated 12 VDC, 2.5 A wall mounted power supply with 2 pin blue connector (100-240 VAC, 50-60 Hz, A-type Plug) $21
Development Kits
Part Description Price
LCD7-STAND Desktop metal support to mount a 7-inch TFT-LCD panel $39
