A Host of Possibilities
With a powerful FPGA at its core, the TS-8820-4100 is a robust, flexible industrial process control systems platform with a packed feature set of various electrically isolated and buffered I/O. The TS-8820-4100 design intent is to meet needs in building automation, including building access, power control, and monitoring. It is suitable for any application that needs multiple robust and optically isolated I/O. The TS-8820-4100 presents ADCs, DACs, Relays, GPIO, CAN, PWMs, Pulse counters, Thermistor-ready, RS-232, RS-485, Power over Ethernet (PoE), and more in an enclosed, DIN-mountable package. For more information, see the TS-8820-BOX product page.
The TS-4100 i.MX 6UltraLite powered system-on-module adds wireless monitoring and control to the complete TS-8820-4100 solution with its built-in WiFi and Bluetooth module as well as a 32-bit microcontroller based on the ZPU inside of the FPGA to offload CPU tasks and allow for hard real-time I/O interactions. For more information, see the TS-4100 product page.
To further the possibilities, embeddedTS can custom tailor the FPGA to suit individual application requirements with custom logic and features. For more information, contact our engineers directly.
| CPU |
| Architecture |
Arm |
| Part Number |
i.MX 6UltraLite |
| Vendor |
NXP |
| CPU Speed |
696 MHz |
| Floating Point Unit |
Yes |
| CPU Cores (Max) |
1x |
| Core Specs |
| Base Memory Capacity |
512 MB |
| Maximum Memory Capacity |
1 GB |
| FPGA |
4 k LUT |
| Watchdog Timer |
1x |
| Storage |
| Base Flash Capacity |
4 GB |
| Flash Type |
eMMC |
| microSD Card Socket |
1x |
| General I/O |
| General-Purpose Input/Output (GPIO) Pins |
46x |
| PWM Ports |
8x |
| Relays |
4x |
| Peripheral Interfaces |
| USB OTG Ports |
2x |
| Serial Interfaces |
| SPI Ports |
1x |
| I2C Ports |
1x |
| I2S Audio Ports |
1x |
| Industrial Protocols |
| CAN Ports |
2x |
| Precision Time Protocol (PTP) |
Yes (Available via kernel update in downloads) |
| Networking |
| 10/100 Ethernet Ports |
1x |
| Physical |
| Operating Supply Voltage |
10 VDC to 30 VDC |
| Fanless Temperature Range |
-40 °C to 85 °C |
| Radio Comms |
| Bluetooth |
Yes (BLE) |
| WiFi Radio / Wireless LAN |
Yes (802.11 b/g/n) |
| Solutions |
| TS-SILO Power Reserve (Super Capacitors) |
Yes |
| Software |
| Linux Kernel Version |
3.14 |
| Debian Linux |
Stretch (9.0) |
| Graphics / HMI |
| Text LCD Header |
1x |
TS-4100 Block Diagram
(Download PDF version)
| Product Configuration |
| Part |
Description |
Price |
| TS-4100-SMN1I |
TS-4100 SoM with i.MX6UL 696MHz Arm Cortex A7, 512MB DDR3 RAM, and 4GB eMMC flash (-40C to 85C)
|
Pricing
|
| TS-4100-SMN2I |
TS-4100 SoM with i.MX6UL 696MHz Arm Cortex A7, 512MB DDR3 RAM, and 4GB eMMC flash, stand-alone version with daughter card interface (-40C to 85C)
|
Pricing
|
| TS-4100-SMW5I |
TS-4100 SoM with i.MX6UL 696MHz Arm Cortex A7, 512MB DDR3 RAM, and 4GB eMMC flash, TS-SILO, WiFi/BT with chip antenna (-40C to 85C)
|
Pricing
|
| TS-4100-SRW8I |
TS-4100 SoM with i.MX6UL 696MHz Arm Cortex A7, 1GB DDR3 RAM, and 4GB eMMC flash, TS-SILO, WiFi/BT with u.FL antenna connector, stand-alone version with daughter card interface (-40C to 85C)
|
Pricing
|
| TS-4100-SRW9I |
TS-4100 SoM with i.MX6UL 696MHz Arm Cortex A7, 1GB DDR3 RAM, and 4GB eMMC flash, TS-SILO, WiFi/BT with u.FL antenna connector (-40C to 85C)
|
Pricing
|
| TS-8820-BOX |
TS-8820 Baseboard with ten 12-position screw terminal type connectors and metal enclosure
|
Pricing
|
| TS-8820-BOX-DIN |
TS-8820 baseboard with 10 12-position screw terminal type connectors and metal enclosure with din mount (system-on-module not included)
|
Pricing
|
| Board Specific Peripherals |
| Part |
Description |
Price |
| PX-H-BRIDGE |
H-Bridge for the TS-8820
|
$10
|
| TS-8820-SILO-BOX |
TS-8820 Baseboard with ten 12-position screw terminal type connectors and metal enclosure with TS-SILO included
|
$0
|
| TS-8820-SILO-BOX-DIN |
TS-8820 Baseboard with ten 12-position screw terminal type connectors, TS-SILO and metal DIN enclosure
|
$0
|
| Flash Media |
| Part |
Description |
Price |
| MSD-8GB-4100 |
TS-4100 bootable 8GB Class 10 microSD card including Arm tool chain, Debian Jessie Linux filesystem, documentation, and further binaries/utilities
|
$30
|
| MSD-8GB-USB-4100 |
TS-4100 bootable 8GB Class 10 microSD card including Arm tool chain, Debian Jessie Linux filesystem, documentation, and further binaries/utilities, includes USB reader
|
$63
|
| Accessories and Extras |
| Part |
Description |
Price |
| CB-USB-A-FEMALE-MICRO |
7" USB 2.0 Type-A Receptacle (Female) to Micro-B cable
|
$9
|
| CB-USB-A-MICRO-GOLD |
3' USB 2.0 Type-A to Micro-B cable
|
$9
|
| CB7-05 |
Null modem cable with a DB9F at each end
|
$10
|
| CN-TSSOCKET-M-10 |
Qty Ten (10) Male 100-Pin High Density Connectors for Custom Baseboard Design
|
$50
|
| CN-TSSOCKET-M-100 |
Qty One Hundred (100) Male 100-Pin High Density Connectors for Custom Baseboard Design
|
$322
|
| CB-ANT-WILC |
Antenna and cable for u.FL WiFi modules
|
$17
|
| Power Supplies |
| Part |
Description |
Price |
| PS-12VDC-REG-FC |
International regulated 12VDC wall mounted power supply w/ leads stripped, tinned and ferruled
|
$21
|
| Development Kits |
| Part |
Description |
Price |
| KIT-8820-4100 |
Development kit includes: PS-12VDC-REG-12PG power supply; CB7-05 cable; MSD-8GB-BLANK micro SD card and USB reader interface; jumpers, jumper wires and other hardware
|
$103
|
